Marine Float Level Controller
Product Name:
Marine Float Level ControllerModel No.:
UQK-652-C/S
Product Abstract:
UQK-652-C/S can be used on oil tank, chemical tank and offshore vessels, to monitoring the liquid level in the tanks and give out alarm signal when the level reach the preset value.- Product Description
UQK-652-C/S Marine Float Level Controller
Technical Specification
-
Model:
UQK-652-C/SA , UQK-652-C/SB , UQK-652-C/SZ -
Material:
Aluminium , Stainless Steel -
Control Range:
200 ~ 5000 mm -
No. Of Ball:
1 ~ 4 -
Protect Pipe:
Φ76mm , Φ89mm -
Float Ball:
Φ60mm , Φ76mm , Φ45mm , Φ28mm -
Contact Capacity:
220V , 0.5A -
Protection:
IP66 , IP68 -
Explosion Proof:
Exd IICT6 -
Working Tem.:
≤ 100℃ -
HS Code:
9026209000 -
Dimension:
L x 200 x 200 mm -
Weight:
25Kg -
Application:
Oil Tank , Chemical Tank , etc... -
Lead Time:
Stock Available. -
Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
-
