YCH Bursting Disc
Product Name:
YCH Bursting DiscModel No.:
YCH
Product Abstract:
Shanghai huali safety device YCH type bursting disc contain sawteeth and tongue skiving, the tongue skiving can avoid the bursting disc flying out after reversing and the sawteeth assist the disc open.- Product Description
China YCH Type Bursting Disc
Technical Specification
-
Origin:
Made In China -
Export Market:
USA, Europe, Japan, Korea, Singapore, Indonesia, India, etc... -
Structure:
Reverse domed YCH type bursting disc with an annular score on the dome. -
Feature:
No fragments and sparks are generated in bursting. -
Anti Fatigue:
It can be used in places with fluctuating pressure. -
Application:
Applied in liquid or gas medium with a low pressure. -
Nominal Diameter:
25mm,32mm,40mm,50mm,65mm,80mm,100mm,125mm,150mm,200mm -
Bursting Pressure:
0.3Mpa ~ 3.5Mpa -
Temperature:
Maximum Service Temperature -196℃ ~ 530℃ -
Disc Material:
Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium -
Holder Type:
Y0JA -
HS Code:
8479909090 -
Dimension:
25mm ~ 200mm -
Weight:
0.5Kg -
Lead Time:
Stock Available. -
Certificate:
ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS -
For More Information:
Please feel free to contact with Lead Marine.
-
