Reverse Domed Tooth Ring Bursting Disc
Product Name:
Reverse Domed Tooth Ring Bursting DiscModel No.:
YE
Product Abstract:
Chengdu ChengHang Industrial Safety Systems YE type and Shanghai HuaLi YE type reverse domed tooth ring bursting disc is combined with a single layer membrane and a sawtooth ring.- Product Description
China Reverse Domed With Sawteeth YE Type Bursting Disc
Technical Specification
-
Origin:
Made In China -
Export Market:
USA, Europe, Japan, Korea, Singapore, Indonesia, India, etc... -
Related Model:
YE, YEJ -
Structure:
Reverse Domed With Sawteeth Bursting Disc -
Feature:
No sparks are generated in bursting. -
Application:
Applicable to vacuum or gas environments with a medium, low or fluctuating pressure. -
Nominal Diameter:
20mm,25mm,32mm,40mm,50mm,65mm,80mm...450mm,500mm,550mm,600mm -
Bursting Pressure:
0.02Mpa ~ 5Mpa -
Temperature:
Maximum Service Temperature -196℃ ~ 530℃ -
Disc Material:
Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium -
Disk Form:
Reverse Domed Tooth Ring Bursting Disc, Reverse Domed Welded Tooth Ring Bursting Disc -
Holder Type:
YJE, Y0JA -
HS Code:
8479909090 -
Dimension:
20mm ~ 600mm -
Weight:
0.5Kg -
Lead Time:
Stock Available. -
Certificate:
ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS -
For More Information:
Please feel free to contact with Lead Marine.
-
