Home > Marine Instrument > Oil Water Interface Detector
Oil Water Interface Detector
Product Name:
Oil Water Interface DetectorModel No.:
TFC-02 , TFS-01
Product Abstract:
The portable oil/water interface detector is designed for measuring the oil-water interface level for cargo tanker, widely used for oil tankers and chemical tankers.- Product Description
China Portable Ullage Oil Water Interface Detector
Technical Specification
-
Related Model:
UBX, UTL-200, T2000-TFC-02, T2000-TFS-01, TSS-01, TSS-02, UTI Meter Rtex, UTI Meter Gtex -
Regulations:
IMO MARPOL 73-78 ANNEX I , IMO RESOLUTION MEPC.5(XIII). -
Function:
Portable measuring system check the tank status for effective management of the storage tank. -
Tape Length:
15M , 30M , 40M -
Diameter of Probe:
34mm -
Accuracy:
±2mm , ±20mm -
Responding Time:
＜3s -
Protection:
IP44 -
Explosion-proof:
ExiaIIBT4 -
HS Code:
9026209000 -
Application:
All kinds of oil and chemical tankers. -
Dimension:
600x350x150mm -
Weight:
7Kg -
Lead Time:
10 Days -
Certificate:
ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
-
