YD Bursting Disc
Product Name:
YD Bursting DiscModel No.:
YD
Product Abstract:
Chengdu Chenghang YD type and Shanghai Huali YD type reverse domed blade bursting disc is a single layer film, matching the holder with knife blades, during reversal of the dome, the knife blades of the holder make the bursting disc burst and release.- Product Description
China Reverse Domed Blade Bursting Disc
Technical Specification
-
Origin:
Made In China -
Export Market:
USA, Europe, Japan, Korea, Singapore, Indonesia, India, etc... -
Structure:
Reverse Domed With Knife Blades YD Type Bursting Disc -
Feature:
No fragments are generated in bursting. -
Application:
Applied in gas and gas-liquid medium with a wide range of bursting pressure. -
Nominal Diameter:
20mm,25mm,32mm,40mm,50mm,65mm,80mm...500mm,600mm,700mm,800mm -
Bursting Pressure:
0.02Mpa ~ 14Mpa -
Temperature:
Maximum Service Temperature -196℃ ~ 530℃ -
Disc Material:
Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium -
Holder Type:
YJ, YJA, YJG -
HS Code:
8479909090 -
Dimension:
20mm ~ 800mm -
Weight:
0.5Kg -
Lead Time:
Stock Available. -
Certificate:
ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS -
For More Information:
Please feel free to contact with Lead Marine.
-
