Marine Boiler Level Gauge

Product Abstract:

ULB-3G Marine Boiler Level Gauge is used to measure the level of marine boiler and other industrial boiler.

Product Description

ULB-3G China Marine Boiler Level Gauge

Basic Information

Glass Material:
Toughened Borosilicate Glass
Body Material:
20Mn Forging Steel
Working Pressure:
ULB-3GR Reflex Type 2.5 Mpa / ULB-3GT Transparent Type 4.0 Mpa
Working Temp.:
ULB-3GR Reflex Type 220 ℃ / ULB-3GT Transparent Type 260 ℃
Connection Flange:
Standard: DIN or JIS or ANSI , Size: 20A or 25A
Medium:
Steam or Water
Measuring Range:
310 ~ 2235 mm
Application:
Marine Boiler , Industrial Boiler
HS Code:
90261000
Lead Time:
Stock Available.
Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
